Carriages and Carriage Parts - Rated by the tine carriage hoisting capability, there are four sizings of hook type blade carriages. The hook type fork carriages have been standardized.
Class I carriages are rated for loads as much as 2000 lbs. The carriage bar spacing utilized for Class I is 13 inches. Class II carriages are rated for loads up to 5,550 lbs. Their carriage bar spacing is sixteen inches. Class III carriages are rated for cargo as much as 10,000 lbs. The carriage bar spacing for this particular class is 20 inches. Class IV carriages are rated for loads up to 15,500 lbs. The carriage bar spacing used for this capacity is 25 inches.
Pin mounted tines differ by the amount of offset between the tine and the tine eye. Different manufacturers will differ the carriages for pin type tines. Carriage capacity would be established by the carriage pin size and by the tine size.
